Line connection and line-side power components
3.8 Line reactors
Booksize Power Units
106 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Line/load connection
Table 3- 17 Line and load connection line reactors for Basic Line Modules
6SL3000-0CE22-0AAx
6SL3000-0CE24-0AAx
6SL3000-0CE31-0AAx
Power
20 kW
40 kW
100 kW
Line supply connection
1U1, 1V1, 1W1
Screw terminals
10 mm
2
;
1.5 ... 1.8 Nm
Screw terminals
35 mm
2
;
5 ... 6 Nm
Copper busbars with 8.5 mm
diameter holes
Load connection
1U2, 1V2, 1W2
PE connection Screw M4
2 Nm
Terminal studs M6
6 Nm
Terminal studs M8
12 Nm
