Line Modules Booksize
4.2 Active Line Modules with internal air cooling
Booksize Power Units
172 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Internal air cooling
6SL3130–
7TE28–0AAx
7TE31–2AAx
Rated power
kW
80
120
DC link currents
Rated DC link current:
for 600 V:
DC link current:
for 600 V DC; for S6 - 40 %
for 600 V DC; peak current
A
DC
A
DC
A
DC
134
176
218
200
244
292
Current carrying capacity
DC link busbar:
24 V busbar:
A
DC
A
DC
200
20
200
20
Electronics current drawn
at 24 V DC
A
DC
1.4
1.8
Total power loss
(including electronics losses, see
Power loss tables (Page 781))
W 1383.6 2243.2
Max. ambient temperature
without derating
with derating
° C
° C
40
55
40
55
DC link capacitance
Active Line Module
Drive line-up, max.
μF
μF
2820
20000
3995
20000
Power factor
cosϕ
1
1
Circuit breaker
(IEC 60947 and UL)
See Section Overcurrent protection using line fuses and circuit
breakers (Page 51)
Rated short-circuit current
SCCR
3)
kA 65 65
Cooling method (internal air cooling)
Mounted fan
Mounted fan
Sound pressure level
dB(A)
< 73
< 73
Cooling air requirement
m
3
/h
520
520
Max. permissible heat sink
temperature
° C 70 75
Rated voltage for rated data 3 AC 380 V
Weight
kg
23
23
1)
The specified power ratings apply to the line voltage range from 380 V to 480 V.
2)
Default for 400 V line systems; undervoltage trip threshold is adjusted to the parameterized rated voltage
3)
The resulting rated short-circuit current is obtained from the combination of the fuse or circuit breaker – and the Line
Module in the drive system.
