Line Modules Booksize
4.9 Smart Line Modules with external air cooling
Booksize Power Units
320 Manual, (GH2), 04/2014, 6SL3097-4AC00-0BP6
Figure 4-98 Opening to mount Smart Line Modules 50 mm to 200 mm with external air cooling, all
data in mm and (inches)
Table 4- 84 Dimensions of openings to mount Smart Line Modules with external air cooling
Module width
W in mm (inches)
w1 in mm (inches)
w2 in mm (inches)
50 mm
41.5
+0.3
(1.63
+0.012
)
20.75
+0.15
(0.82
+0.006
)
--
100 mm
89.5
+0.3
(3.52
+0.012
)
19.75
+0.15
(0.78
+0.006
)
50
±0.15
(1.97
±0.006
)
150 mm
133
+0.3
(5.24
+0.012
)
16.5
+0.15
(0.65
+0.006
)
100
±0.15
(3.94
±0.006
)
200 mm
173
+0.3
(6.81
+0.012
)
11.5
+0.15
(0.45
+0.006
)
150
±0.15
(5.91
±0.006
)
