Siemens COMOS User Manual

13.6 P&ID objects
This chapter contains information about the properties and scripts of P&ID objects that is
important in connection with pipe specs and the link between the pipe part catalog and the
P&ID catalog.
The P&ID objects are preconfigured accordingly in the database.
You can find additional information on this topic in the "P&ID Operation" manual, keyword
"Overview of P&ID objects".
13.6.1
Overview: Data flow between P&ID object and pipe part catalog implementation
Application area
Interaction between P&ID, pipe part catalog, and 3D.
Data flow
The following table provides an overview of data flow between the P&ID object and pipe part
catalog implementation. The data is forwarded via static links:
Pipe spec Nominal diameter 1 Nominal diameter 2
Pipe spec element
Pipe section "Y00T00003.Y00A00052" "Y00T00003.Y00A00744" "Y00T00003.Y00A00744AA02"
P&ID object ""Y00T00003.Y00A00052" "Y00T00003.Y00A00744" "Y00T00003.Y00A00744AA02"
Object from pipe part cat‐
alog
"Y00T00011.Y00A00052" "Y00T00011.Y00A00003AA01" "Y00T00011.Y00A00003AA02"
Nominal pressure
Pipe spec element "Y00T00050AA01.Y00A00090"
Pipe section "Y00T00003.Y00A00746"
P&ID object
Object from pipe part catalog
Database reference
13.6 P&ID objects
PipeSpec Designer
152 Operating Manual, 09/2014, A5E32076948-AA
