Function of the structure object Value of
"ParameterName"
Flange standard system:
The flange system of standards can be found under the following nodes.
DIN/EN:
●
"@30 > M23 > A10 > Y30 > A10 > 1 > A60 > 1 Basic geometry flange
dimensions"
● "@30 > M23 > A10 > Y30 > A10 > 1 > A60 > S2 Flange standards acc. EN
1092/T1 (2007)"
ANSI/ASME:
● "@30 > M23 > A10 > Y30 > A10 > 10 > A60 > A10 Geometry contact face"
● "@30 > M23 > A10 > Y30 > A10 > 10 > A60 > A20 Geometry flange face
dimensions"
● "@30 > M23 > A10 > Y30 > A10 > 10 > A60 > A30 Geometry flange length"
"Flange standard"
Connection type:
The types of joints can be found under the following nodes.
DIN/EN:
● "@30
> M23 > A10 > Y30 > A10 > 1 > A60 > 1 > A20 Geometry flange face
dimensions"
ANSI/ASME:
● "@30 > M23 > A10 > Y30 > A10 > 10 > A60 > A20 Geometry flange face
dimensions"
"Connection type"
Pressure stage:
The geometry tables can be found on the lowest level under the node "@30 >
M23
> A10 > Y30 > A10 > 1 > 60 Basic geometry flange dimensions". This table
describes the pressure stages.
"Nominal pressure"
Other objects for structuring of catalog:
For
example: structure objects for construction lengths, pipe schedules, outside
diameters.
"- - -"
See also
Using the "CatStd(...)" function (Page 32
)
3.4.2.3 Extending the "Standard parameterization table"
You can add new parameters to the existing parameters. COMOS then takes these parameters
into account when calculating the basic tables.
To add parameters, extend the "Standard parameterization table".
"Standard parameterization table"
Database:
"Standard tables > @40 > Y00 > A10 > A90 > Y00N00204 Standard parameterization table"
Preparing for creation and maintenance of pipe specs
3.4 Managing the "standard geometry tables" standard catalog
PipeSpec Designer
Operating Manual, 09/2014, A5E32076948-AA 23

Siemens COMOS Specifications

General

Manufacturer	Siemens
Description	COMOS is plant engineering software for the process industry. It manages plant projects and documentation. It covers the entire plant lifecycle from engineering and design to operation and maintenance.
Functionality	Plant design and engineering
Integration	Integrates with Siemens TIA Portal, SIMATIC PCS 7, and other third-party systems
Data Management	Centralized data management
Modules	Includes modules for process engineering, electrical engineering, instrumentation, and automation
Collaboration	Supports multi-disciplinary team collaboration with role-based access
Documentation	Automated generation of documentation (e.g., P&IDs, loop diagrams, instrument lists), document management, version control.
Customization	Highly customizable to meet specific project requirements and industry standards. Allows for scripting and API integration.
Industry Standards	ISO, IEC
