3.4.2 Structure of the standard catalog for geometry standards
The standard catalog is based on a template that determines the structure of the catalog.
●
The templates of the standard geometry tables can be found under the following node:
"@10 > A20 > A20 > A20 > A10 Geometry tables"
● The preconfigured standard geometry tables can be found under the following node:
"@30 > M23 > A10 > Y30 > A10 Standard geometry tables"
Features of the "standard geometry standards" catalog
The "standard geometry standards" catalog comprises two types of object:
● Structure objects: The nodes in the Navigator tree
They structure the catalog, based on is structure parameters.
● Geometry tables: The tables in the Navigator tree
They save the dimensions of the pipe parts.
3.4.2.1
Structure parameters
Overview
The following parameters structure the standard catalog:
● System of standards (DIN, EN, ANSI, etc.)
● Flange standard system (DIN, EN, ANSI, etc.)
● Connection types
● Part types such as certain flanges, reducers, etc.
● Construction types such as various elbow radii, etc.
● Nominal pressure level
See also
Extending the "Standard parameterization table" (Page 23)
Preparing for creation and maintenance of pipe specs
3.4 Managing the "standard geometry tables" standard catalog
PipeSpec Designer
Operating Manual, 09/2014, A5E32076948-AA 21
