Siemens COMOS User Manual

User interface reference
14
14.1 "PipeSpec Manager" category in properties of the base project
"Start node" control group
The settings in this control group are necessary for the fundamental work with the PipeSpec
Designer. The control group is for information only and cannot be changed.
Field Default Description
"Basic tables, industrial
standards"
"@30 > M23 > A10 > Y30 > A10 Stand‐
ard geometry tables"
Link to the base object node in which the standard cat‐
alog for the geometry standards that is dependent on
the system of standards is searched for.
"Pipe part types" "@30 > M23 > A10 > Y30 > A20 Pipe
part types"
Link to the base object node in which pipe part types
are defined.
"Pipe spec definition" "@50 > A10 > A10 > B10 Pipe spec
catalog"
Link to the base object node in which pipe specs are
searched for.
"System depending tables" "Standard tables > Y10 > M20 > Y30 >
A10 System standard depending ta‐
bles"
Link to the node containing the standard tables that are
dependent on the system of standards.
"Base object for pipe spec" control group
Field Default Description
"Pipe spec folder" "@20 > C90 > A10 > A10 Template for
pipe spec folder"
Link to the base object node that you use when you
want to create a new folder for pipe specs in the pipe
spec catalog.
"COMOS pipe spec" "@20|C90|A10|A20|A20 Template ob‐
ject for pipe spec"
Link to the base object node for COMOS pipe specs.
"Insulation pipe spec" "@20 > C90 > A10 > A40 Template ob‐
ject for insulation spec"
Link to the base object node for pipe specs for insula‐
tion.
"PDMS pipe spec" "@20 > C90 > A10 > A20 > A50 Tem‐
plate object for PDMS pipe spec"
Link to the base object node for PDMS pipe specs.
"Pipe spec template" - -
"Miscellaneous" control group
Field Default Description
"Default encoding for XML
import"
"ISO-8859-1" -
"Connection type table" "Standard tables > Y10 > M23 > A10 >
Y10M23N00004 Connection types"
Link to the standard table of connection types.
"MTO configuration" - Link to the base object node for MTO configuration
objects.
PipeSpec Designer
Operating Manual, 09/2014, A5E32076948-AA 155
