6.4 The "Load pipe spec" window





① Toolbar
② "Name" field
Name of the node currently selected in the lower area.
③ "Description" field
Description of the node currently selected in the lower area
④ ● If you have opened the window in the engineering project:
"Engineering project" tab
●
If you have opened the window in the base project:
"Current project" tab
⑤ ● If you have opened the window in the engineering project:
"Base project" tab
●
If you have opened the window in the base project:
-
"Current project" and "Base project" tabs
In the structure tree you see the node that is entered in the properties of the base object as
the root node for the pipe spec definition.
This is where you define the basic classes/system classes.
Basic
classes/system classes are created in the base project. They are available on a project-
wide basis. They can be used as templates for project-specific pipe specs.
In engineering projects, basic classes/system classes are write-protected.
