Control element Description
"GeoType"
● List for the definition of the GeoType
The corresponding GeoTypes have already been entered in the pipe
part catalog.
● The
GeoType is evaluated when the drawing procedure of the pipe part
is called in the 3D model.
● 3D attribute
"Function code"
● List for the definition of the function code
●
Evaluated in the P&ID and Isometrics modules
"Layer"
● List
specifying a group of objects that are hidden and shown as a group
in 3D space.
"Color"
● Button specifying the color in which the object is to be displayed in 3D
space.
- Cross-section drawing with the legend for the dimensions
"Pipe spec"
● List from which the pipe spec is selected in the engineering data.
"Pipe spec dependent" Option is evaluated if the "CatPC" calculation formula has been called for
the pipe part.
It is evaluated on the "Display for nominal diameter range" tab.
"CatPC" sets the attribute to the value "1".
"VSUI attributes"
● Only visible in the Navigator, not in the properties.
●
Use: To adapt the toolbar in isometries. Not directly PipeSpec-relevant.
● The pipe spec and the nominal diameter of components must be set for
the isometry before you can draw on the isometry. For this purpose, the
following attribute names must be entered as the value:
"Y00A00052;Y00A00003AA01".
See also
Standard table for function codes
(Page 55)
Preparing for creation and maintenance of pipe specs
3.5 Administering pipe part catalogs
PipeSpec Designer
Operating Manual, 09/2014, A5E32076948-AA 51
