U24802-J-Z146-2-7600 RM400 C Models 113

Dokuschablonen Version 3.2 vom 25.10.93 © Siemens Nixdorf Informationssysteme AG 1993

Druck vom 12. 04.1999 16:17.26 Pfad: H:\Christoph\Manuale\PDF\RM\RM400C Betriebsanleitung\englisch\rm400.k10

Drives

The floppy disk drive

The quarter-inch cartridge tape drive

The 4 mm cartridge tape drive

The 8 mm, 5/10 Gbyte cartridge tape drive

The 8 mm, 20/40 Gbyte cartridge tape drive

The CD-ROM drive
