Equipment settings
14
U24802-J-Z146-2-7600 RM400 C Models 167
Dokuschablonen Version 3.2 vom 25.10.93 © Siemens Nixdorf Informationssysteme AG 1993
Druck vom 12. 04.1999 16:17.38 Pfad: H:\Christoph\Manuale\PDF\RM\RM400C Betriebsanleitung\englisch\rm400.k14
14.1.4 Default settings for printers with a serial connection
The printers suitable for the system can be connected as specified in the following
table.
To ensure error-free data transfer between the interface of the system unit and the
printer, the printer must be adapted to the configuration of the interface.
Set the following parameters on the printer:
For information on setting these values on the printer, refer to the relevant operating
manual.
The maximum permitted value for the line speed of V.24 interfaces is 38,400 baud.
The maximum permitted value for your printer can be found in the operating manual
for the respective device.
If you wish to change the default parameter settings, you have to adjust the relevant
interface in the operating system to the new values.
You can use the Config user interface to configure the interfaces (see the manual
“System Administration and Hardware Configuration Using the SYSADM User
Interface”). For more information on printer operation, administration and settings,
refer to the SPOOL V4.2 manuals.
Baud rate: 9600
Parity: None
Data bits: 8
Stop bits: 1
