Online replacement (OLR)
6
U24802-J-Z146-2-7600 RM400 C Models 63
Dokuschablonen Version 3.2 vom 25.10.93 © Siemens Nixdorf Informationssysteme AG 1993
Druck vom 12. 04.1999 16:17.15 Pfad: H:\Christoph\Manuale\PDF\RM\RM400C Betriebsanleitung\englisch\rm400.k06
6.1 Conditions for online replacement (OLR)
Defective magnetic disks (hard disks) can be replaced by new ones while the system
is running. This procedure is described as online replacement (OLR). OLR can take
place under the following conditions:
– under SINIX V5.42 with an optional RAID controller
– under Reliant UNIX with a RAID controller or with the program Config/XConfig
OLR is one of the high-availability components that are provided in the system
cabinet of RM400 C system models or in combination with the corresponding
RM400 BG31/32 and/or the BG4 peripherals cabinet. The OLR procedure ensures
safe and stable system operation.
Figure 38: Hard disk drive in OLR shuttle
OLR-capable hard drives are housed in a 3 1/2" OLR shuttle. The OLR shuttle has
a handle and two LEDs on the front panel.
(1) Ventilation grille
(2) Handle of OLR shuttle.
To remove a drive from the system cabinet you need to fold out this handle
RM400-BG31/32 peripherals cabinet
(installed vertical)
RM400 C system model
(installation horizontally)
1
2
3
