Equipment settings
14
U24802-J-Z146-2-7600 RM400 C Models 165
Dokuschablonen Version 3.2 vom 25.10.93 © Siemens Nixdorf Informationssysteme AG 1993
Druck vom 12. 04.1999 16:17.38 Pfad: H:\Christoph\Manuale\PDF\RM\RM400C Betriebsanleitung\englisch\rm400.k14
Setting the console parameters for terminal type TC20-V100
Set the same parameters here as for terminal type 9766.
Setting the console parameters for terminal type TC10-V100
Set the same parameters here as for terminal type 9766.
Connecting additional terminals
If you wish to connect more terminals in addition to the console, you must configure
the appropriate interfaces using the Config user interface. The parameters listed
above must be set for all V.24 interfaces to which terminals are to be attached. The
terminals must then be adjusted to the interface configuration.
If you wish to change the default parameter settings, you have to adjust
the relevant interface in the operating system to the new values.
The maximum permitted value for the line speed of the V.24 interfaces (direct and
distributor box) is 38,400 baud. The maximum permitted value for your terminal can
be found in the operating manual for the respective device.
You can use the Config user interface to configure the interfaces (see “System
Administration and Hardware Configuration Using the SYSADM User Interface” and
“Hardware Configuration with Config under SINIX/windows”). Practical examples
are provided.
