46 RM400 C Models U24802-J-Z146-2-7600
5
Installing peripherals
Asynchronous terminal controller
Figure 13: Asynchronous terminal controller, EISA (CT11, CT13) - (optional) -
Using this terminal controller and up to four connector boxes with V.24 or V.11 ports
you can attach a total of 64 terminals or printers to the system unit.
Refer to the operating manual for your particular connector box.
Intelligent terminal controller
Figure 14: Intelligent terminal controller (ITC, ISA) - (optional) -
Using the intelligent terminal controller and the SSW16 connector box with IHSS
interfaces you can attach up to 16 terminals or printers per controller to the system
unit via the IHSS interfaces.
Refer to the operating manual for the SSW16 connector box.
