Siemens RM400 C Series User Manual

Installing peripherals 5
U24802-J-Z146-2-7600 RM400 C Models 53
Dokuschablonen Version 3.2 vom 25.10.93 © Siemens Nixdorf Informationssysteme AG 1993
Druck vom 12. 04.1999 16:17.10 Pfad: H:\Christoph\Manuale\PDF\RM\RM400C Betriebsanleitung\englisch\rm400.k05
If you have any questions on the subject of DCE and long-range data transmission
lines, you should consult your local SNI office.
Figure 26: WAN controller with X.21 port (EWAN-L, EISA) (CW11) - (optional) -
Figure 27: WAN controller with V.24 port (EWAN-L, EISA) (CW14) - (optional) -
Figure 28: WAN controller with V.24 and X.21 port (EWAN, EISA) (CW20, CW22) - (optional) -
Figure 29: ISDN S
0
controller (ISA) (CW31) - (optional) -
Figure 30: ISDN S
0
controller (ISA) (CW32) - (optional) -
The second S
0
port is available only if the CW33 option is installed.
. 21
S 0
