Configuration using Web Based Management and Command Line Interface
4.5 The Switch menu
SCALANCE X-300 / X-400
Configuration Manual, 10/2014, C79000-G8976-C187-22
191
If you enable this option, the VLAN-ID of received frames decides how they are forwarded:
To use the VLAN-ID of the received frame, the VLAN must have been created on the IE
switch and the port must be a member of the VLAN.
Frames with the configured port VLAN-ID are forwarded, frames with a different VLAN-ID are
discarded when they are received. Frames without a VLAN-ID are received and forwarded to
the port VLAN-ID.
If you enable this option, the port is a trunk port. A trunk port is automatically a member of all
configured VLANs and only sends tagged frames.
If you disable the option, the VLAN configuration that existed prior to enabling the option is
restored.
Syntax of the Command Line Interface
Table 4- 57 VLAN Port Parameters - CLI\SWITCH\VLAN\PORTS>
info Displays an overview of the ports and corresponding
-
vid [<VLAN-ID> [ports]] Received frames without a VLAN tag at the specified
ports are given a VLAN tag with the <VLAN-ID>.
Administrator
prio [<0...7> [ports]] Specifies the priority of ports. Administrator
ingress [<E|D> [ports]] Enables/disables the evaluation of the VID of re-
Administrator
untagged [<E|D> [ports]] Specifies the processing of frames without a VLAN
tag.
When this is enabled, frames are also accepted
without a VLAN tag, otherwise not.
Administrator
only.
trk [<E|D> [ports]] Enables/disables the trunk property.
The trunk port is automatically a member of all con-
figured VLANs and only sends tagged frames.
Administrator
only.
