Configuration using Web Based Management and Command Line Interface
4.4 The Agent menu
SCALANCE X-300 / X-400
90 Configuration Manual, 10/2014, C79000-G8976-C187-22
You will find further information on PTP in the sections "Precision Time Protocol (PTP)
complying with IEEE 1588 (Page 236)" and "Configuration of the Precision Time Protocol
with the WBM (Page 242)".
Note
Avoiding time jumps
To avoid time jumps, make sure that there is only one time server (SICLOCK time
transmitter, (S)NTP server, PTP master) in the netw
ork.
If there are several time servers in the network, only activate one time protocol.
If you enable this check box, the IE switch browses the network for a DHCP server and
configures its IP parameters according to the data supplied by this server. For detailed
information on this functionality, refer to the section "Assigning addresses with the DHCP
client of the IE switch".
Note
As soon as the IP address has been assigned once by a PROFINET IO controller, DHCP
automatically deactiv
ates itself and must be reactivated if required.
If you enable this check box, the IE switch browses the network for a BOOTP server and
configures its IP parameters according to the data supplied by this server. For detailed
information on this functionality, refer to the section "Assigning addresses with the BOOTP
client of the IE switch".
If you select this option, the device can be accessed and configured via DCP (PST Tool and
STEP 7).
If you select this option, the configuration data can only be read via DCP (PST Tool and
STEP 7).
If you require the IE switch to communicate with devices (diagnostics stations, e-mail
servers, etc.) in a different subnet, you will need to enter the IP address of the default
gateway here.
Enter the VLAN-ID of the agent here.
