Siemens SIMATIC ET 200SP Function Manual

OPC UA communication
9.1 What you need to know about OPC UA
Communication
Function Manual, 11/2019, A5E03735815-AH
137
PLC tags in the address space of the OPC UA server
The figure below shows where the PLC tags in the example are located in the address space
of the OPC UA server (excerpt from UA client):
The "MyDB" data block is a global data block. The data block is therefore located below the
node "DataBlocksGlobal". "StartTimer" is a memory tag and is therefore stored below the
"Memory" node.
Figure 9-4 PLC tags in the address space of the OPC UA server

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
