Siemens SIMATIC ET 200SP Function Manual

OPC UA communication
9.3 Using the S7-1500 as an OPC UA server
Communication
Function Manual, 11/2019, A5E03735815-AH
177
9.3.3.2 Access to the OPC UA server
Server addresses
The OPC UA server of the S7-1500 CPU can be reached over all integrated PROFINET
interfaces of the CPU (firmware V2.0 and higher).
Direct access to the OPC UA server of the CPU over the backplane bus of the automation
system is not possible via CPs under the following conditions:
● Configuration with TIA Portal Version V16 or higher, S7-1500 CPU firmware version 2.8
or higher and CP 1543-1 firmware version V2.2 or higher.
For configuration, see Access to OPC UA applications (Page 131).
Direct access to the OPC UA server of the CPU over the backplane bus of the automation
system is not possible via CMs.
With SIMATIC S7-1500 SW controllers, access to the OPC UA server is possible via
PROFINET interfaces that are assigned to the software PLC.
Additional access options of SW controllers are described in the following application
example: Internal and external OPC UA connection via the virtual Ethernet interface of the
software controller V2.5 or higher
(https://support.industry.siemens.com/cs/ww/en/view/109760541
).
Example for URLs (Uniform Resource Locator) that can be used to set up connections to the
OPC UA server of the CPU:
Figure 9-14 Display of the server addresses

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
