Siemens SIMATIC ET 200SP Function Manual

Communications services
3.1 Overview of communication options
Communication
Function Manual, 11/2019, A5E03735815-AH
21
Communications options
Functionality
Via interface:
PN/IE
1
DP
serial
Web server Data exchange via HTTP(S), for example for diag-
nostics
X - -
SNMP (Simple Network Management
Protocol)
For monitoring and error recognition of IP networks,
possibly parameterization of the IP network compo-
nents via standard SNMP protocol
X - -
Time-of-day synchronization Via PN/IE interface: CPU is NTP client (Network
Time Protocol)
X - -
Via DP interface: CPU/CM/CP is time-of-day master
or time slave
- X -
1
IE - Industrial Ethernet
2
Observe the special characteristics for S7-1500R/H
3
Only via internal PROFINET interface of the CPU and via Ethernet interface CP 1543 1 with activated "Access to PLC
via communication module" function.
Information on S7-1500R/H
You can find information on the communication possibilities with the redundant system
S7-1500R/H in the section Communication with the redundant system S7-1500R/H
(Page 324).
Additional information
● Application example: CPU-CPU communication with SIMATIC controllers (compendium)
You can find the application example on the Internet
(https://support.industry.siemens.com/cs/ww/en/view/20982954
).
● This FAQ (https://support.industry.siemens.com/cs/ww/en/view/102420020) describes
how to configure fetch/write communication via CP1543-1 with S7-1500.
● Additional information about the Fetch/Write services is available in the STEP 7 online
help.
● You can find additional information on the PtP link in the function manual CM PtP -
Configurations for Point-to-Point Connections
(http://support.automation.siemens.com/WW/view/en/59057093
).
● You will find the description of the web server functionality in the function manual Web
server (http://support.automation.siemens.com/WW/view/en/59193560
).
● You will find information about the standard protocol SNMP on the Service & Support
pages on the Internet (http://support.automation.siemens.com/WW/view/en/15166742
).
● You will find information about time-of-day synchronization in this FAQ
(https://support.industry.siemens.com/cs/ww/en/view/86535497
).

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
