Siemens SIMATIC ET 200SP Function Manual

Connection resources
11.1 Connection resources of a station
Communication
Function Manual, 11/2019, A5E03735815-AH
309
Number of connection resources of a station
Table 11- 1 Maximum number of connection resources supported for some CPU types
Connection resources of a
station
1511
1511C
1512C
1513
1515
1516
1517
1518
Maximum connection re-
sources of the station
96 128 192 256 320 384
of which reserved 10
of which dynamic
86
118
182
246
310
374
Connection resources of the
CPU
64 88 108 128 288 320
Max. additionally usable
connection resources by
plugging in CMs/CPs
32 40 84 128 32 64
Additional connection re-
sources CM 1542-1
64
Additional connection re-
sources CP 1543-1
118
Additional connection re-
sources CM 1542-5
40
Additional connection re-
sources CP 1542-5
16
The number of connection resources that a CPU or a communication module supports is
specified in the device manuals in the Technical Specifications.
Example
You have configured a CPU 1516-3 PN/DP with a CM 1542-1 communication module and a
CP 1542-5 communication processor.
● Maximum connection resources of the station: 256
● Available connection resources:
– CPU 1516-3 PN/DP: 128
– CM 1542-1: 64
– CP 1542-5: 16
– Total: 208
The setup provides 208 connection resources. By adding further communication modules,
the station can support a maximum of 48 additional connection resources.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
