Siemens SIMATIC ET 200SP Function Manual

Open User Communication
6.9 Setting up communication via FTP
Communication
Function Manual, 11/2019, A5E03735815-AH
89
Procedure for setting up FTP server functionality
Requirement: The FTP server can be reached via the IPv4 network.
1. Configure an S7-1500 automation system with CPU and CP 1543-1 in the device view of
the Devices & networks editor of STEP 7.
At the same time, you need to select the option "Permit access with PUT/GET
communication from remote partner (PLC, HMI, OPC, ...)" in the HW configuration of the
S7-1500 CPU under the "Protection" area navigation in the section "Connection
mechanisms".
2. Make the following settings in the properties of the CP under "FTP configuration":
– Select the "Use FTP server for S7 CPU data" check box.
– Assign the CPU, a data block and a file name under which the DB for FTP will be
stored.
Figure 6-11 Setting up the FTP configuration
3. Download the hardware configuration to the CPU.

Siemens SIMATIC ET 200SP Specifications

General

System Type	Distributed I/O System
Mounting	DIN Rail
Communication Protocol	PROFINET, PROFIBUS
IP Rating	IP20
Category	I/O Systems
Supply Voltage	24 V DC
Modularity	Yes
Hot Swapping	Yes
Storage Temperature	-40°C to +70°C
Digital Inputs	Yes
Digital Outputs	Yes
Analog Inputs	Yes
Analog Outputs	Yes
Communication Interface	PROFINET, PROFIBUS
Number of Modules	Up to 64
Relative Humidity	5 to 95% (non-condensing)
Operating Temperature	-25°C to +60°C
