Expanding and assigning parameters to the device
6.6 Drives
SIMATIC IPC847E
Operating Instructions, 10/2018, A5E43920357-AA
101
Ambient temperature
0 - 40 °C
Drive configuration
Mode
Non-RAID system
X
RAID1 system
X
RAID5 system X
RAID1 system with hot spare drive
X
RAID5 system with hot spare drive
X
Maximum number of drives per drive type
(in the removable tray or internally on the side panel of the device)
Ambient temperature
0 * - 40 °C
Drive type
Front
Side panel
SATA (2.5" and 3.5" size)
4
2
SATA Enterprise (2.5" and 3.5" size)
4
2
SAS Enterprise (3.5" size)
4
2
* 0 °C minimum permissible temperature for SATA hard disk drive
5°C minimum permissible temperature for SATA Enterprise hard disk drives
