Siemens SIMATIC IPC847E - Motherboard Specifications

Technical specifications
8.7 Technical specifications of the motherboard
SIMATIC IPC847E
158 Operating Instructions, 10/2018, A5E43920357-AA
8.7
Technical specifications of the motherboard
See the note in "Applicability of technical specifications (Page 149)".
Chipset Intel® GL82 C246 PCH
Processor
• Intel® Core i3-8100 *
4C/4T, 3.6 GHz, 6 MB cache
• Intel
®
Core™ i5-8500
6C/6T, 3.0 (4.1) GHz, 9 MB cache, iAMT
• Intel
®
Core™ i7-8700
6C/12T, 3.2 (4.6) GHz, 12 MB cache, iAMT
• Intel
®
Xeon
®
Processor E-2176G
6C/12T, 3.7 (4.7) GHz, 12 MB cache, iAMT
RAID (on-board) Intel
®
PCH with Intel
®
Rapid Storage Technology
Slots for memory modules
4 x DIMM slots for DDR4 2666, expandable to 64 GB
Main memory
4 up to 64 GB, DDR4 SDRAM PC4-2666T
Max. of 3.2 GB can be used for 32-bit versions of operating system and applications;
see order documents for equipment
Power consumption per PCI slot,
maximum permitted
• 5 V / 5 A or 3.3 V / 7 A
• 12 V / 0.5 A
• 3.3 V
aux
/ 0.4 A
Power consumption per PCIe slot
with x4 expansion card, maximum
permitted
• 3.3 V / 3 A
• 12 V / 2.1 A
• 3.3 V
aux
/ 0.4 A
Power consumption per PCIe slot
with x16 expansion cards, max.
permissible
• 3.3 V / 3 A
• 12 V / 2.1 A
• 3.3 V
aux
/ 0.4 A
Power loss per slot with max. am-
bient air temperature 50 °C, per-
missible
≤ 30 W
Power loss of all slots with max.
ambient air temperature 50 °C,
permissible
≤ 80 W
In sum, the current for 3.3 V
aux
may not exceed 1.2 A.
* Main memory interface 2400 MT/s
