Expanding and assigning parameters to the device
6.6 Drives
SIMATIC IPC847E
124 Operating Instructions, 10/2018, A5E43920357-AA
Installing drives inside on the side wall of the device
You can internally mount up to two drives (2.5" and 3.5") on one drive bay plate on the right
side panel of the device (viewed from the front panel).
● An original spare part, i.e. a drive bay plate approved for this device with an appropriate
drive.
● The device is fully disconnected from the line voltage, see "Switching off the device
(Page 60)".
● The device is open, see important information in "Open the device (Page 89)".
1. Screw the drive to the drive bay plate at the highlighted holes.
