Siemens SIMATIC IPC847E - Install M.2 Nvme SSD

Expanding and assigning parameters to the device
6.6 Drives
SIMATIC IPC847E
126 Operating Instructions, 10/2018, A5E43920357-AA
6.6.6
Install M.2 NVMe SSD
Note
An M.2 NVMe SSD cannot be operated in a RAID system.
The M.2 NVMe SSD is plugged onto a PCIe adapter card and then onto the bus board using
this adapter card.
Requirement
● M.2 NVMe SSDs key M with a max. length of 110 mm
● PCIe adapter card
● Cross-tip screwdriver P1
