Technical specifications
8.2 General technical specifications
SIMATIC IPC847E
150 Operating Instructions, 10/2018, A5E43920357-AA
8.2
General technical specifications
See the note in "Applicability of technical specifications (Page 149)".
Article number 6AG4114-3...-.... (for details, refer to the ordering documentation)
Dimensions
481.4 x 176.6 x 446.6 (W × H × D in mm)
Detailed dimensional specifications can be found in "Dimension drawing of the device
(Page 163)".
Weight
15 up to 23 kg; depending on the equipment
Supply voltage (U
N
)
Single power supply: 100 V AC to 240 V AC (-15%; +10%)
Redundant power supply: 2 × 100 V AC to 240 V AC (-15%; +10%)
Input current Single power supply:
• Continuous current at 100 V: ≤ 6 A
• Continuous current at 230 V: ≤ 3 A
• At startup ≤ 80 A for 3.6 ms
Redundant power supply:
• Continuous current at 100 V: ≤ 5 A
• Continuous current at 230 V: ≤ 2.5 A
• At startup ≤ 80 A for 3.6 ms for each module
Information on the dimensioning of fuses in higher-level system circuits
A fuse that is designed for a typical tripping current of 6.3 A is integrated in the power
supply unit of the IPC. The pulse currents during startup are also taken into account
by the "time lag" type. In the case of a fault, this fuse ensures the correct disconnec-
tion of the device from the power supply system.
It is recommended that a fuse of at least 6.3 A, plus the power demand of the other
devices that are also supplied via this circuit, be used for protection of the higher-
level power supply circuit. The tripping characteristic of the higher-level protection
must take into account the starting currents of both the IPC and the other devices.
Frequency of the supply voltage
50 to 60 Hz, min. 47 Hz to max. 63 Hz, sinusoidal
Power consumption with maximum
configuration and 255 W secondary
Single power supply ≤ 290 W with 89% efficiency
Redundant power supply ≤ 290 W with 88% efficiency
Power loss, heat emission
Single power supply: 290 W = 290 J/s = 0.27 BTU/s
Redundant power supply: 290 W = 290 J/s = 0.27 BTU/s
Current output (DC) Single power supply:
• +5 V/25 A, +3.3 V/20 A
190 W permitted in total
• +12 V1/14 A, +12 V2/11 A
• -12 V/0.1 A, +5 V
aux
/2 A
Redundant power supply:
• +5 V/20 A, +3.3 V/20 A
100 W permitted in total
• +12 V1/16 A, +12 V2/16 A
• -12 V/0.5 A, +5 V
aux
/3 A
The total power of all voltages may not exceed 255 W.
