Expanding and assigning parameters to the device
6.4 Internal USB interface
SIMATIC IPC847E
98 Operating Instructions, 10/2018, A5E43920357-AA
Internal USB interface
Requirement
● The device is open, see important information regarding this under Open the device
(Page 89).
● Optional retainer for locking the internal USB interface, see "Hardware accessories
(Page 30)".
● Screwdriver TX10
1. Screw the guide rail of the retainer into place in the enclosure as shown in the figure.
2. Connect the USB stick.
3. Slide the retainer in the direction of the USB stick.
4. Secure the retainer by turning the screw on the guide rail.
