Expanding and assigning parameters to the device
6.6 Drives
SIMATIC IPC847E
Operating Instructions, 10/2018, A5E43920357-AA
117
Vibrations above 500 Hz are not permitted.
③
Additional drive mounted
on the side panel on the
drive bay plate.
④
Drive type "SATA" is po
s-
sible
If drives are mounted on the side panel, these may be exposed to the following vibration
stresses during operation:
● 10 ... 58 Hz: 0.045 mm
● 58 ... 300 Hz: 3 m/s
2
Ambient temperature
0 - 50 °C
Drive configuration
Mode
Non-RAID system
X
RAID1 system
X
RAID5 system
X
RAID1 system with hot spare drive
X
RAID5 system with hot spare drive
-
Maximum number of drives per drive type
(in drive cage type B or internally on the side panel of the device)
Ambient temperature
0 - 50 °C
Drive type
Front
Side panel
SATA
3
2
SATA Enterprise
-
-
