Siemens SIMATIC IPC847E User Manual

Hardware description
A.5 System resources
SIMATIC IPC847E
Operating Instructions, 10/2018, A5E43920357-AA
191
I/O address (hex)
Size
(bytes
)
Description of the basic function
Possible alternative
function
from
to
0000 00A0
0000 00A1
2
Programmable Interrupt Controller
0000 00A4 0000 00A5 2 Programmable Interrupt Controller
0000 00A8
0000 00A9
2
Programmable Interrupt Controller
0000 00AC
0000 00AD
2
Programmable Interrupt Controller
0000 00B0
0000 00B1
2
Programmable Interrupt Controller
0000 00B2
0000 00B3
2
Motherboard resources
0000 00B4
0000 00B5
2
Programmable Interrupt Controller
0000 00B8
0000 00B9
2
Programmable Interrupt Controller
0000 00BC
0000 00BD
2
Programmable Interrupt Controller
0000 00F0
0000 00F0
2
Numeric data processor
0000 02F8
0000 02FF
8
COM 2
0000 03F8
0000 03FF
8
COM 1
0000 04D0
0000 04D1
2
Programmable Interrupt Controller
0000 0680
0000 069F
32
Motherboard resources
0000 0D00
0000 FFFF
768
PCI Express Root Complex
0000 164E
0000 164F
255
Motherboard resources
0000 1800
0000 18FE
255
Motherboard resources
0000 1854
0000 1857
2
Motherboard resources
0000 2000
0000 20FE
255
Motherboard resources
