Operating the device
5.5 Monitoring of the device
SIMATIC IPC847E
84 Operating Instructions, 10/2018, A5E43920357-AA
Status display and actions
Monitoring of the
voltages
• Monitoring of the charge status of the buffer battery
(CMOS)
• When the first warning threshold is reached, the
backup battery will run for at least 1 more month.
• For the redundant power supply, monitoring is per-
formed to check whether both power inputs are ac-
tive and the power supply fans are operating.
• If a critical or error status occurs, an
alarm is output.
• Acoustic alarm for the redundant
power supply
Drive monitoring
• Determination of the status of the drives (HDD and
SSD) with SMART functionality even in RAID sys-
tems (RAID status)
• The status of an inactive hot swap drive is not dis-
played.
• Status display "HDDx ALARM
(Page 25)"
• SMART status of the hard drives
• The following statuses, for example,
are displayed in a RAID system:
"Normal", "OK", "Degraded", error
"Rebuild", rebuilding
Software for device monitoring
You can find information on the monitoring software and its documentation under:
● SIMATIC IPC DiagBase (Page 85) for monitoring and alarm output locally on the device
● SIMATIC IPC DiagMonitor (Page 85) for monitoring and alarm output via the network
SIMATIC DiagBase or SIMATIC DiagMonitor also controls the status displays of the IPC,
see: System status displays (Page 25).
