Interface Submodules
13-8
S7-400, M7-400 Programmable Controllers Module Specifications
A5E00069467-07
13.3.3 Technical Specifications
Technical Specifications
The IF 962-LPT interface submodule receives its supply voltage from the M7-400
programmable modules or from the M7-300/400 expansion modules. The current
consumption given in the technical specifications is the consumption required for
dimensioning the power supply, that is, the current consumption is referenced to
24 V in the M7-300 and to 5 V in the M7-400.
6ES7962-1BA00-0AC0
Technical Specifications
Supply voltage Supplied from the
M7-400
programmable
modules or from the
M7-300/400
expansion modules
Current consumption in the
M7-300
(for dimensioning the 24 V
current supply)
0.21 A
Current consumption in the
M7-400
(for dimensioning the 5 V
current supply)
0.6 A
VGA controller WD90C24
Video controller 1 Mbytes
Submodule ID 81
H
Power losses 2.5 W
Dimensions
W x H x D (mm)
18.2 x 67 x 97
Weight 0.085 kg
