Siemens Simatic M7-400 User Manual

Interface Submodules
13-9
S7-400, M7-400 Programmable Controllers Module Specifications
A5E00069467-07
Operating Modes
The WD90C24 VGA controller is used on the IF 962-VGA interface submodule.
Table 13-7 shows you the video modes supported by the BIOS of the IF 962-VGA
interface submodule.
Table 13-7 Video Modes of the IF 962-VGA Interface Submodule
Mode
(HEX)
Text /
Graphics
Monochrome/
Color
Resolution
(Columns x
Lines)
Number
of
colours
Character
Size
Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
0.1 Text Color 320 x 200 16 8 x 8 31.5 70
0.1 Text Color 320 x 350 16 8 x 14 31.5 70
0.1 Text Color 360 x 400 16 9 x 16 31.3 70
2.3 Text Color 640 x 200 16 8 x 8 31.5 70
2.3 Text Color 640 x 350 16 8 x 14 31.5 70
2.3 Text Color 720 x 400 16 9 x 16 31.3 70
4.5 Graphics Color 320 x 400 4 8 x 8 31.5 70
6 Graphics Monochr. 320 x 200 2 8 x 8 31.5 70
7 Text Monochr. 720 x 350 2 9 x 14 31.3 70
0D Graphics Color 320 x 200 16 8 x 8 31.5 70
0E Graphics Color 640 x 200 16 8 x 8 31.5 70
0F Graphics Monochr. 640 x 350 2 8 x 14 31.5 70
10 Graphics Color 640 x 350 16 8 x 14 31.5 70
11 Graphics Monochr. 640 x 480 2 8 x 16 31.5 60
12 Graphics Color 640 x 480 16 8 x 16 31.5 60
13 Graphics Color 320 x 200 256 8 x 8 31.5 70
54 Text Color 1056 x 344 16 9 x 9 31.1 70
55 Text Color 1056 x 400 16 8 x 16 31.1 70
5F Graphics Color 640 x 480 256 8 x 16 31.5 60
58/6A Graphics Color 800 x 600 16 8 x 8 35.1 56
58/6A Graphics Color 800 x 600 16 8 x 8 37.8 60
58/6A Graphics Color 800 x 600 16 8 x 8 47.7 72
5C Graphics Color 800 x 600 256 8 x 8 35.1 56
5C Graphics Color 800 x 600 256 8 x 8 37.8 60
5C Graphics Color 800 x 600 256 8 x 8 47.7 72
5D Graphics Color 1024 x 768 16 8 x 16 35.6 87
1)
5D Graphics Color 1024 x 768 16 8 x 16 48.4 60
60 Graphics Color 1024 x 768 256 8 x 16 35.6 87
1)
60 Graphics Color 1024 x 768 256 8 x 16 48.4 60
1)
Interlaced mode
