EIP-200S Ethernet/IP Adapter
2.6 Device profile: supported CIP objects
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
33
Attribute
ID
Access
rule
Description
Data type
Default value
Semantics of values
5 Set TCP/IP network
interface config-
uration
STRUCT
of:
Contains parameters re-
quired to operate as a
TCP/IP node. In order to
prevent incomplete or
incompatible configuration,
the parameters cannot be
set individually. The user
should first Get this attrib-
ute, change the desired
parameters, then Set the
attribute.
IP address UDINT Device's
IP address
Value of 0 indicates no
IP address has been con-
figured. Otherwise a valid
Class A, B, or C address
shall be set and shall not
be set to the loopback
address (127.0.0.1).
Network mask UDINT Device's network
mask
Value of 0 indicates no
network mask address has
been configured.
Gateway ad-
dress
UDINT Default gateway
address
Value of 0 indicates no
IP address has been con-
figured. Otherwise a valid
Class A, B, or C address
shall be set and shall not
be set to the loopback
address (127.0.0.1).
Primary name
server
UDINT 0x00000000 Value of 0 indicates no
name server address has
been configured. Other-
wise a valid A, B, or C
address shall be set.
Secondary
name server
UDINT 0x00000000 Value of 0 indicates no
secondary name server
address has been config-
ured. Otherwise a valid A,
B, or C address shall be
set.
Domain name STRING 0x0000 (length =
0, empty STRING)
ASCII characters. Maxi-
mum length is 48 charac-
ters. Shall be padded to an
even number of characters
(pad not included in
length). A length of 0 indi-
cates no domain name is
configured.
