Commissioning and diagnostics
4.1 Configuring the ET 200S
EIP-200S Ethernet/IP Adapter Distributed I/O System
System Manual, 06/2018, A5E44345053-AB
83
Configuration table in your configuration software and address space
The byte and bit addresses result from the sequence of the grouped modules in User
Configured mode.
6ES7138-4CA00-0AA0 PM-E 24 VDC
6ES7131-4BB00-0AB0 2DI 24 VDC
Yes
3 6ES7131-4BB00-0AB0*2DI 24 VDC 0.2 to 0.3
6ES7131-4BD00-0AA0*4DI 24 VDC
6ES7132-4BD00-0AA0 4DO 24 VDC
Yes
6ES7132-4BB00-0AB0*2DO 24 VDC
6ES7132-4HB00-0AB0*2DO Rel.
6ES7138-4CA00-0AA0 PM-E 24 VDC
6ES7132-4BB30-0AB0 2DO 24 VDC
6ES7132-4BB30-0AB0* 2DO 24 VDC
6ES7138-4CA00-0AA0 PM-E 230 VAC
6ES7132-4BB00-0AB0*2DO 24 VDC/0.5 A
6ES7132-4BB00-0AB0*2DO 24 VDC/0.5 A
Yes
If you do not want to group the configuration of the ET 200S distributed I/O system digital
input/output modules and motor starters in a single byte, use only those module designations
without " * " in the hardware catalog of your configuration software.
Each electronic module/motor starter will then occupy one byte in the input or output area of
the process image.
