2-4
SIMATIC TD 200 Operator Interface
C79000-G7076-C272-01
Note
The Simplified Chinese character set requires a Chinese version of Windows or a
Chinese emulator to properly display Chinese characters in the TD 200
Configuration Wizard. You must start the Chinese emulator before you start the
STEP 7–Micro/WIN software.
The following character sets are available to TD 200 messages:
Latin 1: Standard character set for English and Western European languages
(See “TD 200 Latin I Character Set” on page A-8.)
Latin 1 (Bold): Standard character set for English and Western European
languages. Displays bold characters (See the “TD 200 Latin I Character Set” on
page A-8.)
Simplified Chinese: Chinese character set for People’s Republic of China.
(See the “TD 200 Simplified Chinese Character Set” on page A-10.)
Cyrillic: Character set for Eastern European languages (See the “TD 200
Cyrillic Character Set” on page A-9.)
Original TD 200: For TD 200 devices prior to version 2.0 (See “TD 200
Original Character Set” on page A-6.)
Bar Graph: Same as original TD 200 with some characters replaced with
special characters to draw bar graphs. (See “TD 200 Original Character Set” on
page A-6.)
Note
When the character set selection does not match the Windows character set,
characters may not be displayed correctly in the TD 200 Configuration Wizard and
the data block, but they will be correct on the TD 200 display. It also happens if the
font does not support all of the characters.
Confi
urin
the TD 200
