Siemens SIMOTION ADI4 User Manual

SIMOTION ADI4 - Analog Drive Interface for 4 Axes
Manual, 05/2009, 6FC5 297-0BA01-0BP6
3
Preface
Purpose of the manual
This manual describes the functionality and use of the ADI4 - Analog Drive Interface for
4 Axes.
Note
This manual provides information about the hardware and applications of the ADI4. In the
SIMOTION manuals, you will find general information about working with the SIMOTION
SCOUT engineering software, technology objects, etc.
Scope
ADI4 is supported by the following Siemens products:
● SCOUT Engineering System, Version 3.1.1 or later
● SIMOTION Runtime, Version 3.1.1 or later
● SINAMICS V2.1 or later
Organization of information
The information about ADI4 in this manual is organized as follows:
● General
This chapter describes the properties and essential features as well as the higher-level
boundary conditions of the ADI4.
● Hardware description
This chapter describes the interfaces of the ADI4, the control cabinet installation, and the
power supply of the module.
● Parameter assignment
This chapter describes the assignment of ADI4 parameters for PROFIBUS DP and for
functions.
● Commissioning
This chapter presents a commissioning example using absolute and incremental
encoders in conjunction with ADI4.
● Index
The index helps you to locate information in the manual quickly and easily.
