2.6 Dimension drawing
SIMOTION ADI4 - Analog Drive Interface for 4 Axes
30 Manual, 05/2009, 6FC5 297-0BA01-0BP6
2.6 Dimension drawing













Figure 2-2 Dimension drawing: ADI4
1) Necessary clearance to ensure sufficient ventilation
Maximum tightening torque for all screws: 0.8 Nm
