SIMOTION ADI4 - Analog Drive Interface for 4 Axes
Manual, 05/2009, 6FC5 297-0BA01-0BP6
33
Parameter assignment
3
3.1 Boundary conditions of ADI4 DP slave
NOTICE
The following boundary conditions must be taken into account for the operation of an ADI4
DP slave on the PROFIBUS DP:
• An ADI4 DP slave is not a certified DP standard slave as defined by the PROFIDrive
profile. For example, an ADI4 DP slave does not enable acyclic communication.
Therefore, an ADI4 DP slave can only be operated on a DP master specially released
for this purpose.
• An ADI4 DP slave can only be operated on an equidistant PROFIBUS DP. The
minimum DP cycle is 1 ms.
3.2 Requirements
Components for parameter assignment
The following components are required for assigning parameters for an ADI4 DP slave:
● ADI4:
as of order number: 6FC5 211-0BA01-0AA1
Firmware Version 01.02.02 and higher
● SIMATIC STEP 7 Version 5.1 and higher
● SIMOTION
– SIMOTION P or C: SIMOTION V2.1 and higher (SCOUT and Runtime)
– SIMOTION D: SIMOTION V3.1 and higher (SCOUT and Runtime)
