Hardware description
2.7 Technical data
SIMOTION ADI4 - Analog Drive Interface for 4 Axes
Manual, 05/2009, 6FC5 297-0BA01-0BP6
31
2.7 Technical data
Table 2- 16 Technical data of the ADI4 module
Safety
Degree of protection IP20
Protection class Protection class I in accordance with VDE 0106 Part 1: 1982
(IEC 536);
Protection against ingress of foreign bodies and water in
accordance with IEC 529
Approvals UL/CSA, CE
Power consumption
Nominal load 12 W
Maximum 30.2 W
Mechanical specifications
Dimensions WxHxD [mm] 154.4 x 325 x 48.5
Weight Approximately 1.5 kg
Climatic ambient conditions
Heat dissipation Open-circuit-ventilated
Operation Storage/transport
Temperature limits 0 … +55° C -20 to 55 °C/-40 to 70 °C
Relative humidity limits 5 to 95 %
without condensation
5 to 95 %
without condensation
Condensation Not permitted
Atmospheric pressure 700 to 1060 hPa 700 to 1060 hPa
Transportation altitude - -1000 to 3000 m
Shock stress during transportation
Free fall in transport packaging ≤ 1000 mm
