Parameter assignment
3.4 PROFIBUS parameters
SIMOTION ADI4 - Analog Drive Interface for 4 Axes
Manual, 05/2009, 6FC5 297-0BA01-0BP6
35
2. Using a drag-and-drop operation, select the ADI4 DP slave and move it onto to the DP
master system in the station window.
The DP master system is displayed in the station window with the following symbol:
When you release the left mouse button, the DP slave ADI4 is inserted into the configuration.
Note
As you drag the DP slave, the cursor appears as a circle with a slash through it. When the
cursor is positioned exactly over the DP master system, it changes to a plus sign, and the
DP slave can be added to the configuration.
3.4 PROFIBUS parameters
3.4.1 Parameter components
Configuring the PROFIBUS parameters
The PROFIBUS parameters are a result of the following:
● PROFIBUS address
● Number of axes and encoders (message frame type)
● I/O addresses
