Hardware description
2.2 Interface description
SIMOTION ADI4 - Analog Drive Interface for 4 Axes
Manual, 05/2009, 6FC5 297-0BA01-0BP6
23
Relay contact: "Ready" signal
The relay contact remains open or is opened if the module is in one of the following states:
Initialization of the module after Power ON
Power failure or hardware interrupt (NMI)
No cyclic communication to the DP master
PLL error
Synchronization error
Overtemperature
The relay contact is closed if both conditions are present:
Module status "Ready"
Cyclic communication with the DP master
Connection cables
The required connecting cables must be provided by the user:
Supply voltage X6-1, Pin 1 and 12 (P24EXT2):
Wire, conductor cross-section of 1.5 mm
2
(AWG16)
Digital outputs X6-1, Pins 2 to 9:
Wire, conductor cross-section 0.5 to 1.5 mm
2
(AWG20 - AWG16)
Ready X6-1, Pin 10 and 11:
Wire, conductor cross-section of 1.5 mm
2
(AWG16)
NOTICE
The maximum permissible length of the digital signal cable is 30 m.
2.2.8 Interface (X6-2): Digital inputs
Connection
Two 12-pin connectors FK-MCP 1.5/15-ST-3.81 by Phoenix
