Acceptance test and acceptance report
10.5 Acceptance tests
Safety Integrated
272 Function Manual, 05/2010, A5E03264275A
No. Description Status
• r9720.0 = 1 (STO deselected)
• r9722.0 = 0 (STO inactive)
• r0046.0 = 1 (drive in "switch-on inhibit" state)
Acknowledge "switch-on inhibit" and run the drive. Ensure that the correct drive is running. 4.
The following is tested:
• Correct DRIVE-CLiQ wiring between Control Unit and Motor/Power Modules
• Correct assignment of drive No. – Motor/Power Module – motor
• The hardware is functioning properly
• Correct parameterization of the STO function
• Forced Checking Procedure of the Shutdown Paths
