Functions, monitoring, and protective functions
9
9.1 Chapter content
This chapter provides information on:
● Drive functions:
Motor identification, Vdc control, automatic restart, flying restart, motor changeover,
friction characteristic, increase in the output frequency, runtime, simulation operation,
direction reversal, unit changeover
● Active Infeed functions:
line and DC link identification, harmonics controller
● Extended functions:
Technology controller, bypass function, extended brake control, extended monitoring
functions, position control, basic positioner
● Monitoring and protective functions:
Power unit protection, thermal monitoring functions and overload responses, blocking
protection, stall protection, thermal motor protection.
M
~
