SINUMERIK 802D sl Operating and Service Training Manual Page 5
C94
C94
Section 2
Additional G functions in more detail
This is a typical Mill program used on a turning machine, using most addi-
tional G functions.
TOP:
G00 G90 G95 G40 G17
G71
IF R1==2 GOTOF END
T1
M6
G94 S424 F
271 M03 M08
G90 G54 G0 X-35 Y60
G0 Z2
G1 Z0
X100
Y20
X-35
G0 Y-35
G1 Z-10 F1000
G41 X5
Y70 RND=1
0 F271
X72 Y70
X92
Y58
Y10 CHF=1
X4.5
G40
Y-21
G0 Z2
Z100
T2
M6
G94 S800 F
150 M03 M08
G00 G54 X2
5.0 Y0.0 Z50.0
Z10.0
MCALL
CYCLE82( 10.00000, 0.00000, 2.00000, -10.00000, 0.00000,
0.10000)
HOLES2( 0.00000, 0.00
000, 25.00000, 0.00000, 90.00000, 3)
MCALL
G00 G40 X1
50.0 Y150.0 Z150.0
R1=R1+1
GOT
OB TOP
END:
M30
