SINUMERIK 802D sl Operating and Service Training Manual Page 11
C82
C82
Section 4
Handwheel
You can u
se the hand wheel in MCS mode, which allows you to move the axis
with the figures on the
screen having no offsets active.
Press
This will
show the axis as
X1
Y1
Z1
Enabling the
operator to see the difference between
WCS a
nd
MCS sy
stems
HAND WHEEL
s
creen is shown
here in M
CS
Shown here with
MC
S pressed
