Preface 08.02
0
© Siemens AG, 2002. All rights reserved
0-12 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
Caution
Used without safety alert symbol indicates a potentially hazardous
situation which, if not avoided, may result in property damage.
Notice
Used without the safety alert symbol indicates a potential situation
which, if not avoided, may result in an undesirable result or state.
Reference to other
literature
This marking appears wherever specific information can be found in
more detailed reference literature.
References:
The Appendix in this Operator's Guide contains a complete list of
references.
The following symbols are used for the operating elements:
Selection of an operating mode
Soft key
Selection via soft key
Feed Stop/Start keys
Axis/direction selection, e.g. using control stick
JOG keys
