7
Program Creation with EasyStep and G Code 08.02
7.1 General notes
7
© Siemens AG, 2002. All rights reserved
7-130 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
7.1 General notes
Function
You can create parts programs in two different ways with ManualTurn:
EasyStep
programming
The EasyStep function allows you to create a complex, executable
program by chaining elements such as straight lines, tapers, circles
and cycles together. You do not require G code programming
knowledge to use the function. This type of program is called
machining sequence in the following description. This sequence
consists of different program steps.
G code programming
The
G code function (in the extended soft key menu) allows you to
write parts programs in G code with your programming knowledge.
The ManualTurn cycles are available in the G code editor to assist you
in a way you are familiar with.
Main soft key bar
The basic soft key bar offers the soft key functions described below.
Parts program management
Operating mode PROGRAM offers you a parts program management
function under soft key "Directory" (see Section "Parts program
management"). The programs you create are stored there. Existing
programs can be transferred back to the editor for editing.
The parts programs can be imported and exported via the RS-232
interface.
