Turning Simple Contours 08.02
4.2 Turnin
g
with
p
ath dimension in
p
ut
4
© Siemens AG, 2002. All rights reserved
4-66 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
4.2 Turning with path dimension input
Function
The following geometry elements are provided as modes for turning
simple contours:
• STRAIGHT for facing and longitudinal turning
• CONICAL for taper turning
• CIRCLE for radius machining
• You can specify absolute or incremental path dimensions in any of
the available modes.
• The direction pointer in the graphic display area indicates the
current standard direction of travel for the selected geometry
element.
