cles in STOCK REMOVAL mode
5
© Siemens AG, 2002. All rights reserved
5-100 SINUMERIK 840D/810D Operator's Guide ManualTurn (BAM) – 08.02 Edition
5.3 Stock removal/grooving cycles in STOCK REMOVAL mode
The menu tree for STOCK REMOVAL mode can be modified by the
machine manufacturer.
This section describes the menu tree in its original form.
5.3.1 Stock removal cycles
Function
You can select one of five stock removal cycles which are then
selected via the soft keys displayed in STOCK REMOVAL mode.
The stock removal cycles allow internal and external contours to be
faced and machined longitudinally. You can select one of three
technologies, i.e. roughing, finishing and complete machining.
For roughing of the contour, paraxial cuts are generated for the
programmed infeed depth. Once a contour intersection point has been
reached, the resulting residual corners are removed immediately
parallel to the contour. The workpiece is rough-cut down to the
programmed finishing allowance.
